New KTM 1290 Super Duke R released for 2020

John Milbank, BikeSocial Consumer Editor
By John Milbank
BikingMilbank BikeSocial Consumer Editor, John owns a BMW S1000XR, Honda Grom and a 1999 Kawasaki ZX-6R. He's as happy tinkering in the workshop as he is on twisty backroads, and loves every bike ever built (except one). He's bought three CBR600s, a KTM 1050 Adventure, Yamaha MT-10, two Ducati Monsters, several winter hacks, three off-roaders, a supermoto pit bike, a Honda Vision 50 and built his own custom XSR700.





Describing it as a ‘re-beasting, KTM has updated its flag-ship super-naked with a new chassis, updated styling and renewed electronics…



New KTM 1290 Super Duke R released for 2020



How is the new KTM 1290 Super Duke R different to the old one?

For 2020, KTM has shaved 6kg off the claimed dry weight of the 1290 Super Duke R, taking it to 189kg. The Austrians have also taken two litres off the tank capacity, so full of fuel and ready to ride it’ll be lighter still – we estimate it’ll be between 200 and 210kg as you ride away from the petrol pump. Given that Fuelly.com reported an average consumption of 44.8mpg for the Super Duke R in 2018, maximum range of the new bike has been trimmed by about 20 miles, taking it to around 158 miles. That’s assuming fuel economy is unchanged. We’ll have to wait until we get the first review of the 2020 KTM 1290 Super Duke R to find out…



New KTM 1290 Super Duke R released for 2020



Power has increased slightly from 174bhp @ 9,750rpm to 177bhp @ 9,500rpm, while torque is slightly down from 104.0lb-ft (141Nm) @ 7,000rpm to 103.2lb-ft (140Nm) @ 8,000rpm. While complying with Euro5 has seen a very small increase in power, it’s at the expense of torque – only by a fraction, but it’s 14% higher in the rev range too.

The engine’s capacity is unchanged at 1,301cc, while compression has dropped slightly from 13.6:1 to 13.5:1.

Gearing is the same as the previous model and the suspension is now the APEX fork and shock from WP.



New KTM 1290 Super Duke R released for 2020



Brakes are now Brembo Stylema four-piston radially-mounted calipers with cornering ABS (as well as cornering traction control). The rear wheel has also gone up from a 190/55 ZR17 to a 200 section.

The steering angle is 64.8° (it was 65.1°), and trail has decreased by 1mm to 106mm. The wheelbase has increased – from 1,482mm to 1,497mm, while ground clearance has gone from 141mm, up to 160mm, with no change to the seat height of 835mm – this is likely down to the reworking of the exhaust system, which now has two catalytic converters.

The addition of cornering ABS is the main attraction of the new bike, but current owners will probably be happy know they’ll probably be able to ride that little bit further, and potentially have a slightly better mid-range response from their engines. We’ll have to see what the first road test brings…



New KTM 1290 Super Duke R released for 2020



New KTM 1290 Super Duke R 2020 specification

Engine type

2-cylinder, 4-stroke, V 75°

Displacement

1,301 cc

Bore / stroke

108/71 mm

Power

132 kW (180 hp) @ 9,500 rpm

Torque

140 Nm @ 8,000 rpm

Compression ratio

13.5:1

Starter / battery

Electric starter / 12V 12Ah

Transmission

6 gears

Fuel system

Keihin EFI (Throttle body 56 mm)

Control

8 V / DOHC

Lubrication

Pressure lubrication with 3 Eaton pumps

Engine oil

Motorex, SAE 10W-50

Primary drive

40:76

Final drive

17:38

Cooling

Liquid cooling

Clutch

PASC™ slipper clutch, hydraulically operated

Ignition / engine management

Keihin EMS with RBW and cruise control, double ignition

Traction control

MTC (lean-angle sensitive, 3-Mode, disengageable, Track mode optional)

Frame

CrMo-steel trellis frame, powder coated

Subframe

Cast aluminium / Composite

Handlebar

Aluminium, tapered, Ø 28/22 mm

Front suspension

WP APEX, Ø 48 mm

Rear suspension

WP APEX shock absorber

Suspension travel front / rear

125 / 140 mm

Front brake

2 x Brembo Stylema four piston, radially mounted caliper, brake disc Ø 320 mm

Rear brake

Brembo two piston, fixed caliper, brake disc Ø 240 mm

Abs

Bosch 9.1 MP 2.0 (with cornering ABS and SUPERMOTO ABS)

Wheels front / rear

Cast aluminium wheels 3.50 x 17"; 6.00 x 17"

Tires front / rear

120/70 ZR 17; 200/55 ZR 17

Chain

X-Ring 525

Silencer

Stainless steel primary and secondary silencer with two catalytic converters

Steering head angle

64.8°

Trail

106 mm

Wheel base

1,497 mm ± 15 mm

Ground clearance

160 mm

Seat height

835 mm

Fuel tank capacity

approx 16 litres / 3.5 litres reserve

Dry weight

approx. 189 kg
